This is a 1.5 mm pitch wire-to-board connector with 5.9 mm in mounting height and 3.5 mm in depth when mated with the top-entry type through-hole header. The housing lance design improves contact insertion workability. In addition, the combination of high contact force and round pins provides stable contact performance.
・Low-profile and space-saving
・Housing lance system
・Stable contact performance
・Socket compatible with IDC type ZR connector
・Fully shrouded header ensures durability with a secure connection reducing the risk of stress and misalignment
・Compact, low profile design:The ZH connector requires only about 45% of the installation space required by the standard JST 2.0mm (.079") pitch connector.
・Housing lances :The contact retention lances on the resilient housing allow visual confirmation of contact lock-in for easy and secure insertion.
・Reliable contact construction:The dimple at the center of the contact ensures positivecontact and low contact resistance at all times, even when theconnector is subjected to vibration or distortion. Therefore this connector is ideal for use under low current, low voltage conditions.
・Distortion resistant construction:The header is fully shrouded and thus protects the receptacle from damage that could be caused by mating the connectorsat an angle or by other wise mismating the connectors.
・Compatible with the ZR insulation displacement connectors:The same shrouded header can be used for either the ZR IDC-style connector or the ZH crimp style connector. This allows both types of connector to be used interchangeably withoutreplacing the header.
