Molex SlimStack™ 0.40mm (.016”) Pitch SMT Board-to-Board Connectors

Product Overview

Ideal for tight packaging applications such as digital still cameras, Molex’s 0.40mm pitch right-angle boardto-

board system offers the lowest profile and smallest pitch in the market in a new cost-effective design.

Molex’s 0.40mm pitch right-angle SMT board-to-board system is the smallest of its kind in the industry. The systemoffers between 25-40% profile height savings compared to similar competitive versions. Molex has now expandedon its space-savings advantage with a new 503376 series plug that offers enhanced features such as nickel-barrierplating to protect against flux-wicking and a more cost-effective design.Molex developed its new 503376 plug to meet the requirements of digital camera makers who were lookingfor space savings and cost-reductions for various sub-module applications.

• Small pitch and reduced overall size

• Board-placement pegs

• Wide solder tabs

• Friction lock

• Nickel-barrier plating

• New lower-cost assembly method(503376 series only)

• Space savings

• Provide stability during soldering

• Additional PCB retention

• Secure mating retention

• Protects against flux wicking

• Cost savings

The Molex SlimStack™ 0.40mm (.016”) Pitch SMT Board-to-Board Connectors are designed to address the increasing demand for miniaturization and high-performance connectivity in modern electronics. As devices become smaller and more integrated, manufacturers require connectors that offer not only compactness but also robust performance in challenging environments. Molex's innovative design perfectly aligns with these trends, providing the reliability and space efficiency necessary for cutting-edge applications.

Industry-Leading Design for High-Density Applications

With a 0.40mm pitch, this right-angle connector system offers the perfect balance between minimal footprint and high connection density, ensuring efficient space utilization on PCBs. This design is particularly valuable for applications where every millimeter counts, such as in consumer electronics, medical devices, and wearables. The friction lock mechanism ensures secure mating, minimizing the risk of accidental disconnections, making it suitable for high-vibration environments like automotive systems and industrial equipment.

As industries such as IoT, 5G technology, and smart devices rapidly evolve, there’s a growing need for connectors that support high-speed data transmission while remaining cost-effective. Molex addresses this demand with features like nickel-barrier plating that not only protects against flux wicking but also improves signal integrity—critical for high-frequency applications.

Durability and Ease of Assembly

In addition to space savings, these board-to-board connectors offer enhanced durability, ensuring long-lasting performance even in harsh conditions. The wide solder tabs and board-placement pegs provide stability during soldering, reducing errors and ensuring faster assembly times. This makes the connectors highly attractive for industries focusing on mass production and cost-efficient manufacturing, such as consumer electronics and automotive electronics.

The wide solder tabs provide additional PCB retention, offering a sturdy connection that resists mechanical stress. This is particularly important for devices that are subject to regular movement or vibration, such as portable medical devices, industrial controllers, and sensor modules.

Competitive Edge and Market Relevance

As the demand for smaller, lighter, and faster electronics grows, Molex's SlimStack™ connectors are setting a new standard in high-density connector solutions. By incorporating cost-saving features like the lower-cost assembly method introduced in the 503376 series, Molex remains at the forefront of innovation in the connector market. These advancements allow manufacturers to reduce their overall production costs while maintaining the quality and performance required by today’s high-tech devices.

Key Market Trends

With the rise of edge computing, wearable technology, and smart home devices, manufacturers are increasingly looking for connectors that can handle high-speed data in space-constrained environments. The Molex SlimStack™ 0.40mm pitch connectors meet this need by offering reliable, high-performance connections in an ultra-compact form factor.

Furthermore, as the focus on sustainability in electronic design increases, the cost-effectiveness and reliability of these connectors make them an attractive option for manufacturers aiming to reduce waste and improve the lifecycle of their products.

Target Industries and Applications

• IoT Devices: Compact and reliable for sensors and communication modules.

• 5G Infrastructure: Supports high-speed data transmission in compact devices.

• Medical Electronics: Perfect for portable diagnostic tools and monitoring systems requiring secure connections.

• Automotive Electronics: Ideal for space-constrained environments in infotainment systems, sensors, and control modules.

By integrating the latest technological advancements, the Molex SlimStack™ 0.40mm Pitch SMT Board-to-Board Connectors offer an industry-leading solution that meets the requirements of modern, high-performance devices while keeping manufacturing costs in check. Whether in industrial automation, consumer electronics, or automotive systems, these connectors provide a robust, scalable solution that keeps up with the pace of industry innovation.

For businesses looking to integrate Molex SlimStack™ 0.40mm (.016”) Pitch SMT Board-to-Board Connectors into their products, Huamao Cable is your trusted partner. We provide tailored solutions for high-performance connectors to meet the demands of your specific application. Contact us today to learn more about our product offerings, request a quote, or discuss how we can help optimize your electronic designs with cutting-edge connector technology. Let us support your business in staying ahead of industry trends with reliable, cost-effective solutions.
