Molex 501189 Series 1.0mm Pitch Double Row Connector Wire Harness Assembly

Molex 501189 Series 1.0mm Pitch Double Row Connector Wire Harness Assembly

Name: Molex 501189 Series 1.0mm Pitch Double Row Connector Wire Harness Assembly
Brand: Molex
Rating: 5.0 (94 reviews)

Specifications

Molex 501189 Series
· No. of pins: 20 to 50
· Material: PA, UL94V-O
· Operating temperature range: -40°C to 85°C

(incl. temperature rises due to electric conduction)
· Maximum rated voltage: 50 V
· Maximum rated current: 1.0 A
· Contact resistance: 20 mΩ or less
· Withstand voltage: 250 VAC/min
· Insulation resistance: 100 MΩ or higher
· Compatible terminal: 501193
· Compatible headers: 501190, 501571
· Wire Range: AWG#28~32

Model:
Molex 501189 Series
Brand:
Molex
Code:
HM10812A

Availability:

Quantity:



Inquire Add to Basket

1.0 mm Pitch Wire Harness 1.0mm Cable Assembly Molex 501189 Series Cable Molex 501189 Series Cable Assembly Double Row Connector Wire Harness Wire to Board Connector Cable Assembly

Product Description

Molex 501189 Series

Molex Pico-Clasp Wire-to-Board Connectors are small pitch (1.00mm) wire-to-board connectors with positive lock. Pico-Clasp 1.00mm pitch connectors come in single-row and dual-row configurations. The series offers friction and positive locks for various application needs. Pico-Clasp is designed for various connections in flat panel displays (FPD). This Molex connector system is also ideal for use in notebook PCs and other compact devices.The Pico-Clasp 1.00mm-pitch wire-to-board connector system ranges in circuit sizes from 2 to 50 and provides wide header versions, ideal for space constraint applications.The wide range of design options including gold and tin plating, allows additional design flexibility and the simplicity to stay within the product family.

Positive Inner Lock:Offers secure mating retention with low mating and unmating forces.Prevents wire tangling and latch breakage.
Outer positive lock:Secure mating retention.Easy to mate and unmate.

SMT Mounting:Provides assembly and cost efficiencies.Automated assembly reduces manual labor processes.
